ROTULA SOLDAR TERCER PUNTO BASE

REFERENCIA	DIAMETRO A mm	DIMENSION B mm	DIAMETRO C mm	DIMENSION D mm	DIMENSION E mm	DIMENSION F mm	DIMENSION G mm	PESO Kgs	NOTA
WETL0221	19.5	44	30 x 14	36	62			0'420
WETL0222	19.5	44	Ø34	60	60			0'720
WETL0223	20	44	Ø34	60	60			0'720
WETL0224	22.5	51	Ø38	63	75			1'050
WETL0225	25.4	51	Ø38	65	75			1'000
WETL0226	25.4	51	Ø48	70	85			1'610
WETL0227	25.4	51	Ø48	70	85	27x2	25	1'510
WETL0228	30	55	Ø50	65	83			1'410
WETL0229	19	30	Ø25	48	53			0'360
WETL0230	19	44	Ø25	48	53			0'390
WETL0231	32	51	Ø38	85	90			1'400
WETL0232	25.4	51	Ø50	65	83			0'475
WETL0233	30	51	Ø50	70	80			1'560
WETL0234	30	51	Ø50	70	80	27x2	27	1'460
WETL0235	29	55	Ø50	65	83			1'410
WETL0236	35	55	Ø50	65	83			1'280
WETL0237	40	75	Ø60	85	108			3'600
WETL0238	40	75	Ø60	85	108	38x2	28	3'600
WETL0239	45	75	Ø60	85	108			3'600
WETL0240	45	75	Ø60	85	108	38x2	28	3'600
WETL0241	50	75	Ø60	85	108			3'600
WETL0242	50	75	Ø60	85	108	38x2	28	3'600
WETL0243	50	100	75	87	140			4'000
