ANILLA DE ELEVACION MACHO

REFERENCIA	ROSCA mm	DIAMETRO "A" mm	DIMENSION "B" mm	DIAMETRO "C" mm	DIMENSION "D" mm	DIAMETRO "E" mm	DIAMETRO "G" mm	MAXIMO LIMITE DE CARGA Kgs	PESO Kgs	NOTA
LEB1801	M6X1	6	11	14	27	26	14	75	0'020
LEB1802	M8X1.25	8	13	20	36	36	20	140	0'060
LEB1803	M10X1.5	10	17	25	45	45	25	230	0'110
LEB1804	M12X1.75	12	20.5	30	53	54	30	340	0'180
LEB1805	M14X2	12	20.5	30	53	54	30	460	0'190
LEB1806	M16X2	14	27	35	62	63	35	700	0'280
LEB1807	M18X2.5	14	27	35	62	63	35	850	0'290
LEB1808	M20X2.5	16	30	40	71	72	40	1200	0'450
LEB1809	M22X2.5	16	30	40	71	72	40	1500	0'465
LEB1810	M24X3	20	36	50	90	90	50	1800	0'740
LEB1811	M27X3	21	41	55	100	96	55	2700	1'015
LEB1812	M30X3.5	24	45	60	109	108	65	3600	1'660
LEB1813	M33X3.5	28	54	70	128	126	75	4300	2'625
LEB1814	M33FX2	28	54	70	128	126	75	4300	2'625
LEB1815	M36X4	28	54	70	128	126	75	5100	2'650
LEB1816	M36FX3	28	54	70	128	126	75	5100	2'650
LEB1817	M42X4.5	32	63	80	147	144	85	7000	4'030
LEB1818	M42FX3	32	63	80	147	144	85	7000	4'030
LEB1819	M48X5	38	68	90	168	166	100	8600	6'380
LEB1820	M48FX3	38	68	90	168	166	100	8600	6'380
LEB1821	M56X5.5	42	78	100	187	184	110	11500	8'800
LEB1822	M56FX4	42	78	100	187	184	110	11500	8'800
LEB1823	M64X6	48	90	110	208	206	120	16000	12'400
LEB1824	M64FX4	48	90	110	208	206	120	16000	12'400
