BARRA DE TIRO (76 X 32)

REFERENCIA	NUMERO DE AGUJEROS	DIMENSION "A" mm	DIMENSION "B" mm	DIMENSION "C" mm	DIAMETRO "D" mm	DIAMETRO "E" mm	DIMENSION "F" mm	DIMENSION "G" mm	PESO Kgs	NOTA
DB0781	5	861	60.5	740	28.4	27	140	115	14'000
DB0782	6	800	58	684	28.4	20	104.5	95	15'150
DB0783	7	750	55	640	28	25.5	80	80	11'800
DB0784	7	876	50	776	28	28	100	96	14'200
DB0785	7	890	64	762	28	29	126	85	13'960
DB0786	7	890	55	780	28	28	124	88.6	14'300
DB0787	7	925	50	825	28.4	25	172.5	80	15'350
DB0788	7	930	55	820	28	28	110	100	15'100
DB0789	7	930	55	820	28	26	85	109	15'200
DB0790	7	932	62	807	28	26	49.5	86.2	15'100
DB0791	7	940	60	820	28.4	28.5	152	86	15'100
DB0792	7	940	55	830	28	30(2), 26(5)	85	110	15'100
DB0793	7	940	55	830	28	26	85	110	15'400
DB0794	7	981	60	861	28.4	28.5	154.5	92	15'900
DB0795	9	800	70	660	28	28.4	70	65	11'740
DB0796	9	910	55	800	28	25.5	80	80	14'555
DB0797	9	945	60	825	28	22	92.5	80	15'400
DB0798	9	945	60	825	28	33	92.5	80	14'300
DB0799	9	962	51	860	28.5	33	110	80	14'900
DB0800	9	980	55	870	28	25.5	87	87	15'900
DB0801	11	825	55	715	28	22	87.5	65	12'980
DB0802	11	932	60	812	28	28	86	64	14'230
DB0803	11	933	55	823	28	22	86.5	65	15'000
DB0804	11	933	60	813	28	28.5	81.5	65	14'200
DB0805	11	960	55	850	28	26	100	65	15'200
DB0806	11	960	55	850	28	22	100	65	15'600
DB0807	11	960	62	836	28	28	78	68	14'700
DB0808	13	932	60	812	28	19	76	55	14'950
DB0809	13	940	60	820	28	19	76	55.6	15'100
DB0810	13	940	60	820	28	22.4	76	55.6	14'750
