BARRA DE TIRO (63 X 25)

DESCRIPCION DE PRODUCTO	INGLES	FRANCES	REFERENCIA	NUMERO DE AGUJEROS	DIMENSION "A" mm	DIMENSION "B" mm	DIMENSION "C" mm	DIAMETRO "D" mm	DIAMETRO "E" mm	DIMENSION "F" mm	DIMENSION "G" mm	PESO Kgs	NOTA
BARRA DE TIRO (63 x 25)	DRAW BARS (63X25)	BARRES A TROUS (63 x 25)	DB0701	3	580	50	480	22	22	120	120	4.802
BARRA DE TIRO (63 x 25)	DRAW BARS (63X25)	BARRES A TROUS (63 x 25)	DB0702	4	420	57	306	22	22	66	58	2.419
BARRA DE TIRO (63 x 25)	DRAW BARS (63X25)	BARRES A TROUS (63 x 25)	DB0703	5	540	50	440	22	22	80	70	4.113
BARRA DE TIRO (63 x 25)	DRAW BARS (63X25)	BARRES A TROUS (63 x 25)	DB0704	7	610	51	508	22	22	83	57	4.742
BARRA DE TIRO (63 x 25)	DRAW BARS (63X25)	BARRES A TROUS (63 x 25)	DB0705	7	610	51	508	16	16	74	60	4.802
BARRA DE TIRO (63 x 25)	DRAW BARS (63X25)	BARRES A TROUS (63 x 25)	DB0706	7	780	54	672	22	22	97.5	80	6.716
BARRA DE TIRO (63 x 25)	DRAW BARS (63X25)	BARRES A TROUS (63 x 25)	DB0707	9	660	57	546	22.2	19.5	76	63.5	5.058
BARRA DE TIRO (63 x 25)	DRAW BARS (63X25)	BARRES A TROUS (63 x 25)	DB0708	9	775	57	661	22	22	114	54	6.329
BARRA DE TIRO (63 x 25)	DRAW BARS (63X25)	BARRES A TROUS (63 x 25)	DB0709	11	774	57	660	22	19	75	51	6.332
BARRA DE TIRO (63 x 25)	DRAW BARS (63X25)	BARRES A TROUS (63 x 25)	DB0710	11	775	57.5	660	22	22.4	75	51	6.084
