HORQUILLA PERNO ROSCADO

REFERENCIA	DIAMETRO "A" mm	DIMENSION "B" mm	DIAMETRO "C" mm	ROSCA pulgadas	PESO Kgs	NOTA
SHSP0601	6.35	25.8	7.93	5/16" UNC	0'060
SHSP0602	7.93	31.75	9.52	3/8" UNC	0'100
SHSP0603	9.52	36.51	11.11	7/16" UNC	0'140
SHSP0604	11.11	42.85	12.7	1/2" UNC	0'240
SHSP0605	12.7	49.21	15.87	5/8" UNC	0'340
SHSP0606	15.87	63.5	19.05	3/4" UNC	0'500
SHSP0607	19.05	76.2	22.22	7/8" UNC	1'250
SHSP0608	22.22	82.55	25.4	1" UNC	1'630
SHSP0609	25.4	95	28.57	1-1/8" UNC	2'450
SHSP0610	28.57	107.95	31.75	1-1/4" UNC	3'180
SHSP0611	13.75	114.3	34.92	1-3/8" UNC	4'310
