PERNO ENGANCHE APEROS 2

REFERENCIA	DIAMETRO "A" mm	DIMENSION "B" mm	DIMENSION "C" mm	ROSCA "D" mm	DIAMETRO "E" mm	DIMENSION "F" mm	DIMENSION "G" mm	DIMENSION "H" mm	PESO Kgs	NOTA
LAP0401	22	46	45	18X1.5	18	130	5	37	0'410
LAP0402	22	50	40	20X1.5	20	130	5	38	0'460
LAP0403	22	50	40	22X1.5	22	140	14	38	0'516
LAP0404	22	50	40	22X1.5	28	140	14	38	0'540
LAP0405	22	51	38	20X1.5	20	128	10	36	0'520
LAP0406	22	51	38	20X1.5	20	128	10	36	0'520
LAP0407	22	60	40	22X1.5	22	150	20	38	0'600
LAP0408	22	60	40	22X1.5	28	150	20	38	0'600
LAP0409	22	60	40	22X1.5	25	150	20	32	0'600
LAP0410	25	60	40	22X1.5	25	150	20	40	0'640
LAP0411	25	60	40	22X1.5	28	150	20	38	0'640
LAP0412	28	50	30	30X2	30	155	50	50	0'700
LAP0413	28	60	45	22X1.5	22	150	14	44	0'716
LAP0414	28	55	45	22X1.5	24	150	14	42	0'725
LAP0415	28	55	45	24X1.5	24	150	15	43	0'800
LAP0416	28	60	40	22X1.5	28	150	20	43	0'750
LAP0417	28	55	45	27X1.5	28	150	14	42	0'890
LAP0418	28	58	48	27X1.5	27	147	10	43	0'875
LAP0419	28	58	48	27X1.5	27	147	10	50	0'875
LAP0420	28	60	45	22X1.5	22	150	14	44	0'890
LAP0421	28	60	40	22X1.5	22	150	20	44	0'890
LAP0422	28	60	40	22X1.5	24	150	20	44	0'890
LAP0423	28	62	38	22X1.5	28	147	20	50	0'870
LAP0424	28	64	38	27X1.5	28	160	25	44	0'910
LAP0425	28	65	30	30X2	30	160	40	50	0'910
LAP0426	28	71	40	30X2	30	160	30	50	0'910
LAP0427	36'500	61	60	27X1.5	27	165	11	50	1'100
LAP0441	22	51	54	7/8"UNF	22	149	11	36	0'520
LAP0442	22	51	48	3/4"UNF	19	140	6	36	0'500
LAP0443	22	51	43	5/8"UNF	22	140	11	36	0'500
LAP0444	22	51	38	7/8"UNF	28'600	146	22	36	0'515
LAP0445	22	51	50'800	1"UNF	25'400	146	9'500	36	0'515
LAP0446	22	51	38	7/8"UNF	28'600	138	14	36	0'490
LAP0447	22	51	45	7/8"UNF	22	140	10	34	0'500
LAP0448	22	64	56	7/8"UNF	22'200	165	16	38	0'525
LAP0449	28	51	60	1-1/8"UNF	28'600	159	16	44	0'775
LAP0450	28'600	51	42	7/8"UNF	22	133'500	11	43	0'700
LAP0451	28'600	51	36'500	3/4"UNF	25'400	149	24	44	0'725
LAP0452	28'600	57	60	1-1/8"UNF	28'600	159	16	43	0'800
LAP0453	28'600	60	50'800	1"UNF	25'400	149	9'500	44	0'700
LAP0454	28'600	60	54	3/4"UNF	19	149	6'300	44	0'700
LAP0455	28'600	60	38	7/8"UNF	28'600	149	22	44	0'700
LAP0456	28'600	60	35	7/8"UNF	22	136'500	12'700	44	0'650
LAP0457	28'600	60	44	7/8"UNF	22	145	12'700	44	0'680
LAP0458	28'600	63'150	54	7/8"UNF	22'200	160	14	44	0'715
LAP0459	36	54	48	1-1/8"UNF	28'600	149	16	52	0'850
LAP0460	36'500	58	45	1-3/8"UNF	35	149	14	52	0'830
LAP0491	22	51	50'800	1-1/8"UNC	28'600	146	9'500	38	0'515
LAP0492	28'600	60	51	1-1/8"UNC	28'600	149	9'500	43	0'700
