BARRA DE TIRO (80 X 40)

REFERENCIA	NUMERO DE AGUJEROS	DIMENSION "A" mm	DIMENSION "B" mm	DIMENSION "C" mm	DIAMETRO "D" mm	DIAMETRO "E" mm	DIMENSION "F" mm	DIMENSION "G" mm	PESO Kgs	NOTA
DB07121	3	770	56	658	28.5	26.5	164.5	164.5	14'000
DB07122	3	960	55	850	28	28.5	212.5	141.5	16'000
DB07123	5	1000	60	880	28	28	160	140	16'250
DB07124	5	1084	60	964	28.5	26	202	140	17'250
DB07125	6	890	63	764	28	28	132	100	14'500
DB07126	7	862	60	742	28.5	26	122	83	14'250
DB07127	7	930	55	820	28	28.5	102.5	102.5	15'750
DB07128	7	934	57	820	28	28	110	100	15'750
DB07129	7	940	60	820	28.5	26	125	95	15'750
DB07130	7	1085	60	965	36	33	152.5	110	17'250
DB07131	7	1094	65	964	36	32	152	110	17'250
