BARRAS DE TIRO (63X25)

REFERENCIA	NUMERO DE AGUJEROS	DIMENSION "A" mm	DIMENSION "B" mm	DIMENSION "C" mm	DIAMETRO "D" mm	DIAMETRO "E" mm	DIMENSION "F" mm	DIMENSION "G" mm	PESO Kgs	NOTA
DB0701	3	580	50	480	22	22	120	120	4'802
DB0702	4	420	57	306	22	22	66	58	2'419
DB0703	5	540	50	440	22	22	80	70	4'113
DB0704	7	610	51	508	22	22	83	57	4'742
DB0705	7	610	51	508	16	16	74	60	4'802
DB0706	7	780	54	672	22	22	97.5	80	6'716
DB0707	9	660	57	546	22.2	19.5	76	63.5	5'058
DB0708	9	775	57	661	22	22	114	54	6'329
DB0709	11	774	57	660	22	19	75	51	6'332
DB0710	11	775	57.5	660	22	22.4	75	51	6'084
